| Auxiliary Power | 12 Volts DC |
| Capacity - Fuel Tank | 40 gal. / 151.42 L |
| Engine Type - Diesel | DEUTZ TD 2.9L Tier 4 Final 67 hp |
| Performance | |
| Axle Oscillation | 0 in. / 0 mm |
| Drive Speed - 4WD | 1.60 mph / 2.57 km/h |
| Gradeability - 4WD | 55 % |
| Platform Capacity - Unrestricted | 500 lb / 226.80 kg |
| Swing | 360 Degrees |
| Swing Type | Continuous |
| Turning Radius - Outside | 0 in. / 0 mm |
| Jib - Range of articulation | 132 Degrees |
| Dimensional Data | |
| Ground Clearance | 1 ft 3 in. / 0.38 m |
| Machine Height | 8 ft 5 in. / 2.57 m |
| Machine Length | 33 ft 6 in. / 10.21 m |
| Machine Width | 8 ft 2 in. / 2.49 m |
| Platform Dimension A | 3 ft / 0.91 m |
| Platform Dimension B | 8 ft / 2.44 m |
| Platform Height | 66 ft 8 in. / 20.32 m |
| Tailswing | 3 ft 8 in. / 1.12 m |
| Track Width | 1 ft 8 in. / 0.51 m |
| Reach Specifications | |
| Horizontal Jib Rotation | 0 Degrees |
| Horizontal Outreach | 56 ft 9 in. / 17.3 m |
| Platform Height | 66 ft 8 in. / 20.32 m |
| General | |
| Capacity - Hydraulic Reservoir | 32 gal. / 121.13 L |
| Machine Weight | 27100 lb / 12292.35 kg |
